Automotive water and wastewater treatment

Trevi treats and reuses the water from car and component manufacturing, from pretreatment and painting to rinsing and cleaning. We separate each stream at the source, treat it to discharge limits and recover what can be reused as process water.

Every water stream treated on its own

Every water stream treated on its own

Degreasing, e-coat, paint shop and rinse water each get the treatment that fits.

From audit to operation

From audit to operation

One partner for audit, pilot, design, build and follow-up.

Water reuse up to a closed loop

Water reuse up to a closed loop

Rinse and process water goes back into production, with evaporation where needed.

Diagram illustrating water streams and treatment steps in automotive manufacturing

Water challenges in the automotive industry

Car plants produce many different water streams: oily wastewater from degreasing, rinse water with zinc and nickel, paint residues and solvents. Each stream has its own pollutants, so one end-of-pipe plant is rarely the most efficient answer. Discharge limits are getting stricter, and many plants also want to cut their freshwater use.

Water treatment along the production line

Degreasing baths remove oil and grease from the car body, and their rinse water carries that load into the wastewater. Separating the oil early keeps the rest of the treatment stable.

  • Pollutants: oils, fats, surfactants, COD
  • Treatment: oil separation, physicochemical treatment, biological treatment
  • Reuse: recovered rinse water for the degreasing line

Conversion coating, such as zinc phosphating, gives the body its corrosion protection. The rinse water contains metals and phosphate that must be removed before discharge.

  • Pollutants: zinc, nickel, manganese, phosphate
  • Treatment: precipitation, coagulation/flocculation, selective ion exchange
  • Reuse: rinse water recovery with ion exchange

The e-coat bath applies the first paint layer. Ultrafiltration recovers paint from the rinse water and returns it to the bath, which saves paint and water at the same time.

  • Pollutants: paint solids, solvents, COD
  • Treatment: ultrafiltration, biological treatment
  • Reuse: paint and rinse water back to the bath

Spray booths capture overspray in circulating water. That water needs continuous conditioning to remove paint sludge and keep the booth running.

  • Pollutants: paint sludge, solvents, COD
  • Treatment: coagulation, sludge separation, biological treatment
  • Reuse: conditioned booth water stays in circulation

Rinse water from all steps is often only lightly polluted. With the right polishing it becomes process water again, which lowers both water intake and discharge load.

  • Pollutants: low concentrations of metals and salts
  • Treatment: membrane filtration, ion exchange, evaporation
  • Reuse: rinse water back to the process

How we approach automotive projects

Study & consultancy

We start by understanding your challenge and advising you on the most effective and future-proof approach.

Lab tests

Our in-house lab simulates real conditions to assess feasibility, determine the right technologies and optimise system performance early on.

Pilot installations

We set up pilot systems at your site under real-life conditions to test feasibility and gather critical data.

Design & build

From engineering to installation, we handle your project from start to finish.

Maintain & operate

We keep your systems running safely and efficiently, offering ongoing support, monitoring and operational expertise.
Study consultancy
Lab test
Pilot installations
Design build
Maintain
Industrial water efficiency assessment for BREF and permit compliance

BREF compliance and water reuse

Automotive sites performing surface treatments fall under the scope of two EU BREFs: Surface Treatment of Metals (STM) and Surface Treatment using Organic Solvents (STS). Compliance with these BREFs means adhering to the BAT-AELs (Best Available Techniques – Associated Emission Levels) for parameters like heavy metals and solvents, and aiming for the BAT-AEPLs (Associated Environmental Performance Levels), such as:

  • Specific water use in m³ per car
  • Waste generation in kg per car
  • Discharge load per vehicle produced (e.g. kg COD per car, g Ni per car)

Reusing rinse water and treated wastewater helps meet both.

Read about BREF

FAQ

Each stream is treated where possible at the source: oil separation for degreasing water, precipitation for metal-bearing rinse water and biological treatment for organic pollutants. Membranes, ion exchange or evaporation then recover water for reuse.

Sites with surface treatment fall under the EU BREFs for Surface Treatment of Metals (STM) and Surface Treatment using Organic Solvents (STS), which set emission levels for heavy metals and solvents and performance levels for water use per car.

Yes. Rinse water in particular can often be recovered as process water with membrane filtration, ion exchange or evaporation.

Talk to a water expert

Tell us about your water streams and discharge limits. A Trevi water expert will look at the options for treatment and reuse.
